Protect drains and inlets WITHOUT lifting any grates
If speed of installation and convenience top the list of features you are looking for in a stormwater product, then the Ultra-Inlet Guard should be a serious consideration.
Heavy-duty geotextile material effectively removes oil and sediment from rainfall. And strong, rare earth magnets sewn into each corner make installation quick and easy.
Product Highlights
- Keeps dirt, sand, sediment, trash, and debris out of drains.
- Quick and easy installation using built-in magnets — no more lifting of heavy catch basin grates.
- Available in several sizes for street drains, combination drains, and trench drains. Custom sizes also available.
- Heavy-duty, material (non-woven, polypropylene geotextile) allows up to 92 gal/ft2/min. through drains.
- Low-profile design can be driven over and is unobtrusive to traffic and personnel.
- Geotextile material helps remove oil and other hydrocarbons from stormwater flow.
| Part # | Model | Dimensions in. (mm) | Weight lbs. (kg) |
|---|---|---|---|
| 9160 | Oil & Sediment Plus Model | 24 x 24 x 0 (609.6 x 609.6 x 0) | 5 (2.3) |
| 9161 | Oil & Sediment Plus Model | 36 x 24 x 0 (914.4 x 609.6 x 0) | 5 (2.3) |
| 9162 | Oil & Sediment Plus Model | 48 x 24 x 0 (1219.2 x 609.6 x 0) | 5 (2.3) |
Swipe to scroll table
| Part # | Model | Dimensions in. (mm) | Weight lbs. (kg) |
|---|---|---|---|
| 9163 | Oil & Sediment Plus Model, Curb Style | 24 x 24 x 0 (609.6 x 609.6 x 0) | 5 (2.3) |
| 9164 | Oil & Sediment Plus Model, Curb Style | 36 x 24 x 0 (914.4 x 609.6 x 0) | 5 (2.3) |
| 9165 | Oil & Sediment Plus Model, Curb Style | 48 x 24 x 0 (1219.2 x 609.6 x 0) | 6 (2.7) |
Swipe to scroll table
Custom sizes available. Minimum order required. Contact us for details.
FAQs
Resources & Docs
Compliance & Regs
Additional Info.
FAQs
Frequently Asked Questions
-
Why would I use the Ultra-Inlet Guard Plus instead of one of your other stormwater management products?
The Ultra-Inlet Guard Plus is one of, if not, the easiest stormwater management products to install. No grates to lift, no fabric to pinch, no cutting necessary. Simply line it up with the grating and lay it on top. The magnets do all the work.
In addition to the ease of installation, the fact that the unit lays on top of the drain means that clean up (dirt/sediment/trash/debris removal) is as simple as sweeping off the surface. The grate doesn’t have to be lifted or removed because everything is kept at street level.
-
Why WOULDN'T I use the Ultra-Inlet Guard Plus instead of one of your other stormwater management products?
The Ultra-Inlet Guard Plus is held in place by magnets. These are exceptionally strong magnets and more than enough to keep the unit in place under normal circumstances. However, unlike products that are installed under the grating, the Ultra-Inlet Guard Plus is more susceptible to damage from street sweepers and to theft/vandalism.
Also, because the units are held in place by magnets at each corner, the Ultra-Inlet Guard Plus is not a “one size fits all” type of product. Some of UltraTech’s stormwater management products can be trimmed/cut to fit the drain but the Ultra-Inlet Guard Plus must match the drain dimensions very closely in order for it to be effective.
-
How many magnets are used in each Ultra-Inlet Guard Plus?
The 24″ x 24″ and 24″ x 36″ size have four magnets each, one in each corner. The 24″ x 48″ size has six magnets, four in each corner and one centered on both of the 48″ sides.
-
Are the magnets removable/replaceable?
No, the magnets are sewn into the material and cannot be removed without damaging the Ultra-Inlet Guard Plus.
Resources & Docs
Compliance & Regs
Helps Comply with These Rules & Regulations
- Stormwater Management Regulation 40 CFR 122.26
- National Pollutant Discharge Elimination System (NPDES)
- Total Maximum Daily Load (TMDL)
Additional Info.
Additional Product Information
Uniform Product Codes (UPCs)
- UPC 808416091601 Ultra-Inlet Guard Plus Oil & Sediment Plus Model (Part #9160)
- UPC 808416091618 Ultra-Inlet Guard Plus Oil & Sediment Plus Model (Part #9161)
- UPC 808416091625 Ultra-Inlet Guard Plus Oil & Sediment Plus Model (Part #9162)
- UPC 808416091632 Ultra-Inlet Guard Plus Oil & Sediment Plus Model, Curb Style (Part #9163)
- UPC 808416091649 Ultra-Inlet Guard Plus Oil & Sediment Plus Model, Curb Style (Part #9164)
- UPC 808416091656 Ultra-Inlet Guard Plus Oil & Sediment Plus Model, Curb Style (Part #9165)
