A reusable solution to keep silt, sediment, and other debris out of curb inlets
The Ultra-Gutter Guard® is a practical, reusable solution designed to tackle the problem of clogging in stormwater drainage systems. It is made from recycled synthetic fibers and engineered to capture silt and other debris from stormwater before it enters the curb inlets. During extreme rainfall, the built-in overflow ports enable water to flow freely, preventing the guard from becoming blocked and causing water to back up.
Unlike other gutter guards, the Ultra-Gutter Guard® doesn’t require any installation; it can be placed directly in front of the curb inlet with at least a 12″ overlap on each side. It is washable, reusable, and available in three different lengths.
Product Highlights
- Available in various lengths.
- Made of 100% recycled materials.
- Washable & reusable.
| Part # | Model | Dimensions in. (mm) | Dimensions ft. (m) | Weight lbs. (kg) |
|---|---|---|---|---|
| 9320 | Ultra-Gutter Guard - 9" Dia. x 8' L | 96 x 9 x 9 (2438.4 x 228.6 x 228.6) | 8 x .8 x .8 (2.4 x .2 x .2) | 15 (6.8) |
| 9321 | Ultra-Gutter Guard - 9" Dia. x 10' L | 120 x 9 x 9 (3048 x 228.6 x 228.6) | 10 x .8 x .8 (3 x .2 x .2) | 19 (8.6) |
| 9322 | Ultra-Gutter Guard - 9" Dia. x 12' L | 144 x 9 x 9 (3657.6 x 228.6 x 228.6) | 12 x .8 x .8 (3.7 x .2 x .2) | 22 (10) |
| 9323 | Ultra-Gutter Guard - 9" Dia. x 16' L | 192 x 9 x 9 (4876.8 x 228.6 x 228.6) | 16 x 0.8 x 0.8 (4.9 x 0.2 x 0.2) | 29 (13.15) |
Swipe to scroll table
FAQs
Resources & Docs
Compliance & Regs
Additional Info.
FAQs
Frequently Asked Questions
-
Why should I choose the Ultra-Gutter Guard instead of one UltraTech's other curb inlet products?
For one, the Ultra-Gutter Guard is made from 100% recycled materials. So if your company/agency has any directives for prioritizing environmentally-friendly products, the Ultra-Gutter Guard would certainly meet those criteria. Another good reason, is ease of use. Installation of the Ultra-Gutter Guard is as simple as laying it down in front of the inlet. And removal is just as easy.
-
Why shouldn't I choose the Ultra-Gutter Guard instead of one UltraTech's other curb inlet products?
From an aesthetic standpoint, the Ultra-Gutter Guard, may not be the best option. It also is more obtrusive than some of our other products which may prove to be less than ideal in areas with a lot of pedestrian traffic or that use street sweeper equipment.
-
What size Ultra-Gutter Guard do I need?
We recommend an Ultra-Gutter Guard that is at least 24″ longer than the inlet so that there is 12″ or more of overlap on either side of the opening.
-
Can the Ultra-Gutter Guard be reused?
Yes. The Ultra-Gutter Guards can be reused and moved from drain to drain. If necessary, the units can be rinsed off to remove dirt, mud, sediment, etc. before moving.
-
Why are there holes in the middle of the Ultra-Gutter Guard?
The holes in the middle of the Ultra-Gutter Guards are overflow ports. In the event of large amounts of rainfall, the overflow ports will allow water to pass through untreated in order to prevent ponding and/or flooding.
-
What other products could be used instead of the Ultra-Gutter Guard?
The Ultra-Gutter Guard Plus and Ultra-Filter Socks are both potential alternatives to the Ultra-Gutter Guard. You can also check out the Path to the Perfect Product to see what other products might be a good option.
Resources & Docs
Compliance & Regs
Helps Comply with These Rules & Regulations
- Stormwater Management Regulation 40 CFR 122.26
- National Pollutant Discharge Elimination System (NPDES)
- Total Maximum Daily Load (TMDL)
Additional Info.
Additional Product Information
Uniform Product Codes (UPCs)
- UPC 808416093209 Ultra-Drain Guard® Ultra-Gutter Guard - 9" Dia. x 8' L (Part #9320)
- UPC 808416093216 Ultra-Drain Guard® Ultra-Gutter Guard - 9" Dia. x 10' L (Part #9321)
- UPC 808416093223 Ultra-Gutter Guard® Ultra-Gutter Guard - 9" Dia. x 12' L (Part #9322)
- UPC 808416102260 Ultra-Gutter Guard Ultra-Gutter Guard - 9" Dia. x 16' L (Part #9323)
