Spill containment, also known as bunding, comes in all types of shapes and sizes. And when it comes to containing really large vessels like frac tanks, tanker trucks, and other large vehicles the Ultra-Containment Berm is often the solution.
But when spill containment needs to be “super-sized,” a product like the Ultra-Containment Wall is necessary. The hard-walled, high-capacity spill containment bund wall system is ideal for multiple vehicle containment areas like those found in the oilfields or when a taller wall / more containment capacity is necessary. The modular bund walls and corners can be quickly set up and reconfigured as containment needs change.
NOTE: Unless otherwise noted, all listed product measurements are L x W x H, outside dimensions, and for a single unit where quantity is more than one.
| Part # | Model | Product Image | Dimensions in. (mm) | Weight lbs. (kg) |
|---|---|---|---|---|
| 8760 | 1 ft. (0.3 m) - Straight Section | 119.5 x 12 x 12 (3035.3 x 304.8 x 304.8) | 33 (15) | |
| 8761 | 1 ft. (0.3 m) - Corner Section | 21.9 x 21.9 x 12 (555.8 x 555.8 x 304.8) | 9 (4.1) | |
| 8762 | 2 ft. (0.6 m) - Straight Section |  |
99.8 x 24 x 24 (2533.7 x 609.6 x 609.6) | 70 (31.8) |
| 8763 | 2 ft. (0.6 m) - Corner Section |  |
35.3 x 29.3 x 24 (895.4 x 743 x 609.6) | 26 (11.8) |
| 8764 | 3 ft. (0.9 m) - Straight Section |  |
72 x 24 x 36 (1829.1 x 609.6 x 914.4) | 60 (27.2) |
| 8765 | 3 ft. (0.9 m) - Corner Section |  |
30 x 30 x 36 (762 x 762 x 914.4) | 36 (16.3) |
| 8770 | 30 ml Textured Polyethylene Liner |  |
Varies | 0.5 (.2) |
| Part # | Model | Dimensions ft. (m) | Quantity | Containment Capacity gal. (L) | Weight lbs. (kg) |
|---|---|---|---|---|---|
| 8790 | 1 ft. Wall Height System | 10 x 49 x 1 (3 x 14.9 x .3) | 12-Straight, 4-Corners, 1-Liner (15 x 62.5 ft) | 3978 (15058) | 754 (342) |
| 8791 | 1 ft. Wall Height System | 68 x 68 x 1 (20.7 x 20.7 x .3) | 28-Straight, 4-Corners, 1-Liner (75 x 75 ft) | 34802 (131740) | 2066 (937.1) |
| 8792 | 2 ft. Wall Height System | 16 x 55 x 2 (4.9 x 16.8 x .6) | 18-Straight, 4-Corners, 1-Liner (25 x 65 ft) | 13716 (51921) | 1821 (826) |
| 8793 | 2 ft. Wall Height System | 63 x 63 x 2 (19.2 x 19.2 x .6) | 32-Straight, 4-Corners, 1-Liner (75 x 75 ft) | 60089 (227462) | 3450 (1564.9) |
| 8794 | 3 ft. Wall Height System | 11 x 55 x 3 (3.4 x 16.8 x .9) | 24-Straight, 4-Corners, 1-Liner (25 x 70 ft) | 14336 (54268) | 2157 (978.4) |
| 8795 | 3 ft. Wall Height System | 61 x 61 x 3 (18.6 x 18.6 x .9) | 44-Straight, 4-Corners, 1-Liner (75 x 75 ft) | 83582 (316392) | 3958 (1795.3) |
The 30 MIL polyethylene (LLDPE) textured liner is held on the walls with 8-foot long clips. These clips snap over the liner and the straight section walls (see image in gallery).
Please note that our liners are made from rolls of material that are 12 feet wide. So the liner that comes with your Ultra-Containment Wall system may be considerably larger than the overall footprint of the system. Any excess material can easily be trimmed with a utility knife. NOTE: The liner in our product photos was trimmed to better show the walls and corners. Typical/recommended procedure for trimming (if any is needed) is to trim the liner as close to the ground as possible. This allows for more movement/adjustments as the system “settles”.
The components overlap when connected to provide additional support/security. Because of this overlap, the overall dimension of a system is shorter.
Yes. Please contact us for more information and minimum purchase quantities.
At this time, the 1, 2 and 3-foot heights are the only ones that are available.
Yes, the walls stack for easier storage and shipping.
Because of the design of the system, a drain cannot be installed.
