Protected by the industry’s strongest warranty – Five years against any material or workmanship defects. Learn more…
The Ultra-Spill Pallet is specially constructed to support heavy loads and designed to be easily used and transported. Its 100% polyethylene (LLDPE) construction makes it compatible with a wide range of chemicals, while its low-rise walls allow easier accessibility for pouring.
It helps meet spill containment regulations for up to four drums, and comply with SPCC and EPA spill containment requirements.
Innovative “Cross of Life” design protects the pallet’s structural integrity during heavy loads over time. As more weight is applied to the top of the pallet, the Cross of Life design draws the all-polyethylene sides towards the center instead of allowing them to sag outwards. Learn more…
NOTE: Unless otherwise noted, all listed product measurements are L x W x H, outside dimensions, and for a single unit where quantity is more than one.
| Part # | Model | Dimensions in. (mm) | Grating Surface in. (mm) | Weight Capacity UDL lbs. (kg) | Containment Capacity gal. (L) | Weight lbs. (kg) |
|---|---|---|---|---|---|---|
| 1010 | P2 Pallet Model Without Drain | 53 x 29 x 16.5 (1346.2 x 736.6 x 419.1) | 48 x 24 (1219.2 x 609.6) | 3000 (1360.8) | 66 (249.8) | 63 (28.6) |
| 1011 | P2 Pallet Model With Drain | 53 x 29 x 16.5 (1346.2 x 736.6 x 419.1) | 48 x 24 (1219.2 x 609.6) | 3000 (1360.8) | 66 (249.8) | 63 (28.6) |
| Part # | Model | Dimensions in. (mm) | Grating Surface in. (mm) | Weight Capacity UDL lbs. (kg) | Containment Capacity gal. (L) | Weight lbs. (kg) |
|---|---|---|---|---|---|---|
| 1000 | P4 Pallet Model Without Drain | 53 x 53 x 11.8 (1346.2 x 1346.2 x 298.5) | 48 x 48 (1219.2 x 1219.2) | 6000 (2721.6) | 66 (249.8) | 90 (40.8) |
| 1001 | P4 Pallet Model With Drain | 53 x 53 x 11.8 (1346.2 x 1346.2 x 298.5) | 48 x 48 (1219.2 x 1219.2) | 6000 (2721.6) | 66 (249.8) | 90 (40.8) |
| Part # | Model | Product Image | Dimensions in. (mm) | Containment Capacity gal. (L) | Weight lbs. (kg) |
|---|---|---|---|---|---|
| 0678 | Ramp for P1 Plus, and P4 Pallets (Excluding P4 Plus) |  |
68.5 x 28.5 x 12 (1739.9 x 723.9 x 304.8) | 318 (1203.8) | 73 (33.1) |
| 1006 | P4 Pullover Cover |  |
13 x 12 x 5 (330.2 x 304.8 x 127) | N/A | 7 (3.2) |
| 1016 | P2 Pullover Cover | |
13 x 11 x 3 (330.2 x 279.4 x 76.2) | N/A | 7 (3.2) |
The 4-drum model is forkliftable from all four sides. The 2-drum model is forkliftable from either of the two longer (53″) sides.
No, we do not recommend moving loaded pallets.
The P2 spill pallet is taller (16.5″) than the P4 spill pallet (11.75″). A ramp to reach that height would have to be fairly long in order to make a safe and effective slope. The cost to make such a large ramp is cost prohibitive. If you are interested in a 2-drum pallet that has a ramp available, we suggest looking at the Ultra-Spill Pallet Plus Models.
The EPA requirements (40 CFR 264.175) do call for 55-gallons. So the Ultra-Spill Pallets EXCEED those federal requirements. However, when these pallets were introduced to the market, there was another requirement in the Uniform Fire Code. That requirement is no longer in effect but called for a 66-gallon sump capacity.
Yes, there are two different ways that it can be done. Both are easy to do and inexpensive. Please contact us for more information.
Good arguments can be made for either option so it is difficult to give a single recommendation. Some users prefer to have a drain to make clean-up easier. If a spill occurs, the drain plug can be unscrewed and the contents can drain out into an appropriate container. Others feel that the drain plug is something that could be unscrewed (for cleaning or maintenance) and then forgotten. Needless to say, that would make for a very ineffective spill containment pallet.
The standard drain is a threaded hole in the sidewall with a ¾” polyethylene plug with NPT threads installed.
We recommend using a pump like the Bladder Pump (Part# 2345) used with our Ultra-Spill Deck Bladder Systems. Click here to see a video of it in action.
The Ultra-Spill Pallet P4 can be stacked up to eight (8) high. The Ultra-Spill Pallet P2 can be stacked up to six (6) high. Both are freight class 150 and NMFC 150390-4.
