The Ultra-Twin IBC Hard Top ships completely assembled and ready to go upon arrival. However, we can ship a disassembled unit to reduce shipping space. Please contact us for more information on this option.

The 535-gallon sump is continuous.  In other words, a spill from one side will eventually make its way over to the other side.  There is no barrier to separate the two sides.  It is important to note that chemicals stored on the Ultra-Twin IBC Hard Top must be compatible.

The standard drain is a threaded hole in the sidewall with a ¾” polyethylene plug with NPT threads installed.

No, the spill pallet is not completely waterproof.  It is more accurately described as weatherproof.  In other words, in standard weather conditions, your drums and/or containers should be protected and water gathering in the pallets is not a concern.  However, during very gusty conditions or very heavy rainfall, some water may get into the unit.  It is good practice to inspect the interior of the hard top after any severe weather.

No.  IBCs, tanks, totes, drums and other items must be removed from the pallet surface prior to moving it.

Each side of the Ultra-Twin IBC Hard Top has a usable surface that is 52″ x 52″.  This surface comprised of two removable grates that are each 26″ x 52″.

There is a single point where the top “rolltop” door meets with the bottom “swing-out” doors. Please note that each side of each compartment requires its own padlock.  In other words, a total of four (4) padlocks are required to secure one Ultra-Twin IBC Hard Top.

There is a center wall that separates the two compartments.

The pallet has an 8,000 lb. per side capacity.  This is for uniformly distributed loads.  An IBC that is supported by pedestal post or feet focuses all of its weight on those feet.  If the dimensions of those feet are not large enough to properly displace the weight on the spill pallet’s grating, it could be an issue.  As a precaution, steel plates (at least 12″ x 12″) can be used under the feet in order to more evenly distribute the weight over a greater area.  If you have any concerns about your IBCs weight, please contact us at 904-292-1611.

UltraTech’s general response to this question is at least ten (10) years. You can expect longer, but the actual life is dependent on several factors. UltraTech has been making outdoor spill containment products since 1993. We have a good sense of realistic life expectancy based on all those years of experience. UltraTech uses the highest-rated UV package in the resin formulation it uses to create the longest outdoor life available for a PE product

The most important environmental factors are ultraviolet exposure and chemical exposure. In the absence of chemical compatibility concerns (determined by the UltraTech compatibility chart for PE products), the next most important factor for outdoor, polyethylene spill containment products will be ultraviolet irradiation (UV) exposure. The most important factors with reference to UV are thickness, UV Inhibitor (UVI) content, and pigment color, type, and concentration. Ultraviolet irradiation exposure causes molecular structure and bond changes that result in the embrittlement of PE. Very thin PE can become brittle and fracture in less than a year (think contractor’s PE Visqueen sheeting). Thicker parts take longer to break down. The addition of UV Inhibitors to the PE allows it to sustain more UV exposure without breaking down. Darker pigments, inorganic pigments, and higher concentrations of pigments also individually and collectively will give PE a longer life before appreciable UV damage occurs.

There is an outdoor spill containment product that has been in use in northeast Florida since 1986 and is still in active use today. UltraTech suggests its Ultra-Track Pans, used for outdoor railroad track spill containment, have a minimum of a twenty-year life.
