Ultra-IBC Spill Pallet®
Plus Model
Protected by the industry’s strongest warranty – Five years against any material or workmanship defects. Learn more…
Economical and portable containment for IBCs
The Ultra-IBC Spill Pallet Plus provides economical and portable spill containment for IBCs, tanks and other large containers. A 365-gallon containment sump helps meet EPA and SPCC spill containment regulations. All polyethylene (LLDPE) construction provides excellent chemical compatibility and forklift pockets makes it easy to move.
Product Highlights
- Low profile, 26" overall height - allows safe and convenient IBC tank handling and dispensing.
- All-polyethylene construction - offers excellent chemical resistance and will not rust or corrode.
- Forkliftable - allows convenient positioning to desired locations.
- Low-cost design with value-added features and benefits.
- Large 52" x 52" deck allows safe and convenient placement of IBC tanks.
- Small footprint - 62" x 62" unit requires minimal floor space.
- 365-gallon sump capacity meets SPCC and EPA Container Storage and Spill Containment Regulations.
- Optional pull over cover keeps rainwater out of sump and helps comply with stormwater management regulations.
- Five inner polyethylene (LLDPE) columns support uniformly distributed loads of up to 8,500 lbs. All components are easily removed for cleaning.
- Optional bucket shelf captures spills from dispensing. Spills that exceed 3 gallons are channeled into the 365-gallon sump through a bulkhead fitting.
Constructed with the "Cross of Life” Design
Innovative “Cross of Life” design protects the pallet’s structural integrity during heavy loads over time. As more weight is applied to the top of the pallet, the Cross of Life design draws the all-polyethylene sides towards the center instead of allowing them to sag outwards. Learn more…
NOTE: Unless otherwise noted, all listed product measurements are L x W x H, outside dimensions, and for a single unit where quantity is more than one.
| Part # | Model | Dimensions in. (mm) | Weight Capacity UDL lbs. (kg) | Containment Capacity gal. (L) | Weight lbs. (kg) |
|---|---|---|---|---|---|
| 1157 | IBC Plus Without Drain | 62 x 62 x 26 (1574.8 x 1574.8 x 660.4) | 8500 (3855.5) | 365 (1381.7) | 230 (104.33) |
| 1158 | IBC Plus With Drain | 62 x 62 x 26 (1574.8 x 1574.8 x 660.4) | 8500 (3855.5) | 365 (1381.7) | 230 (104.33) |
Swipe to scroll table
| Part # | Model | Product Image | Dimensions in. (mm) | Weight lbs. (kg) |
|---|---|---|---|---|
| 1160 | Ultra-Bucket Shelf |  |
19.5 x 16 x 14.5 (495.3 x 406.4 x 368.3) | 10 (4.5) |
| 1159 | Pull Over Cover |  |
63.5 x 63.5 x 52 (1612.9 x 1612.9 x 1320.8) | 10 (4.5) |
Swipe to scroll table
Quick and Easy Pouring or Draining Into IBC Tanks
The heavy-duty, all-polyethylene, Ultra-IBC Funnel makes quick work of any pouring or draining necessary for intermediate bulk containers (IBCs). The funnel locks into place and the built-in strainer fits directly into the top of the tote.
FAQs
Resources & Docs
Compliance & Regs
Additional Info.
FAQs
Frequently Asked Questions
-
What are the dimensions for the forklift pockets?
-
Can I move this pallet with an IBC on top?
No, we do not recommend moving loaded spill pallets.
-
Why would I choose the Ultra-IBC Spill Pallet Plus over the Ultra-IBC Spill Pallet?
The Ultra-IBC Spill Pallet Plus has a lower profile (26”), is forkliftable, and less expensive.
-
Why wouldn’t I choose the Ultra-IBC Spill Pallet Plus over the Ultra-IBC Spill Pallet?
If you have a need for a larger sump capacity or a greater weight capacity, then the Ultra-IBC Spill Pallet may be a better option for you.
-
How large of an IBC can I store on the Ultra-IBC Spill Pallet Plus?
According to the Federal Regulations (40 CFR 264.175), you can store an IBC with a capacity of up to 365 gallons. However, local regulations can be more stringent so it is important to contact your local authorities to ensure compliance.
-
Is the Ultra-IBC Spill Pallet Plus forkliftable?
Yes, there are forklift pockets on two sides of the pallet.
-
Can the Ultra-IBC Spill Pallet Plus be moved with a forklift while there is a full tank on top of it?
It is not recommended.
-
Can the Ultra-IBC Spill Pallet Plus support an IBC that has pedestal posts for legs, or just flat bottom IBCs?
The pallet has an 8,500 lb. capacity. This is for uniformly distributed loads. An IBC that is supported by pedestal post or feet focuses all of its weight on those feet. If the dimensions of those feet is not large enough to properly displace the weight on the spill pallet’s grating, it could be an issue. As a precaution, steel plates (at least 12″ x 12″) can be used under the feet in order to more evenly distribute the weight over a greater area. If you have any concerns about your IBCs weight, please contact us at 800-353-1611 / 904-292-1611.
-
How is the Ultra-IBC Spill Pallet Plus shipped?
The pallet is shipped via truck on an oversized wooden pallet to avoid damage in transit. We can stack them up to 3 high.
-
What is the Ultra-IBC Spill Pallet Plus made of?
Our pallets are made of 100% polyethylene (LLDPE) which provides superior chemical compatibility and corrosion resistance.
-
Can you stack two IBCs on top of the Ultra-IBC Spill Pallet Plus?
As long as the two IBCs combined—including their combined liquid contents—fall within the weight and containment requirements of this product, stacking no more than two IBCs is acceptable.
-
Is the Ultra-IBC Spill Pallet Plus available with a drain?
Yes, the Ultra-IBC Spill Pallet Plus is available either with a drain (Part# 1158) or without a drain (Part# 1157).
-
What type of drain is used for these pallets?
The standard drain is a threaded hole in the sidewall with a ¾” polyethylene plug with NPT threads installed.
-
Can the Ultra-IBC Spill Pallet Plus be used outdoors?
The Ultra-IBC Spill Pallet Plus is made of 100% polyethylene (LLDPE) so it won’t rust or corrode. It also has UV inhibitors so it will last for many years in the sunlight without degrading. HOWEVER, the biggest consideration for using the Ultra-IBC Spill Pallet Plus outside is rain. If the sump is filled (even partially) with rainwater, it has lost or reduced its capacity to capture a spill from the IBC that’s on top of it. There are a few ways to address this issue:
- Place the IBC and the pallet somewhere where there is a roof/shade or some other form of overhead protection to keep the rain and elements out.
- Use the optional pull over cover (Part #1159) and place it over the IBC and pallet.
- Instead of purchasing the Ultra-IBC Spill Pallet Plus, buy the Ultra-IBC Hard Top which has a built-in rigid polyethylene (LLDPE) cover.
- Add an Ultra-Self Bailer to the spill pallet sump. This unit will allow clean water to pass through while filtering out any gas, oil or other hydrocarbons.
-
Are there any other accessories that I should know about?
Yes, the Ultra-Bucket Shelf is an excellent complement to the pallet. It slides securely into built-in grooves in the side of the pallet and captures any incidental leaks or spills that may occur when liquids are being dispensed from your IBCs. If you order the bucket shelf at the same time as your pallet we will also install a bulkhead fitting so that any liquids that are captured are directed into the pallet’s sump.
-
What’s with the columns inside of the sump and do they need to be installed a certain way?
The columns provide the internal support and there is a correct way for them to be installed. If you do not have instructions or have any questions, please contact us.
Resources & Docs
More Info / Downloads
Compliance & Regs
Helps Comply with These Rules & Regulations
- EPA Container Storage Regulation 40 CFR 264.175
- Spill Prevention, Control and Countermeasure Act (SPCC) 40 CFR 112
Additional Info.
Additional Product Information
Uniform Product Codes (UPCs)
- UPC 808416011579 Ultra-IBC Spill Pallet Plus IBC Plus Without Drain (Part #1157)
- UPC 808416011586 Ultra-IBC Spill Pallet Plus IBC Plus With Drain (Part #1158)
- UPC 808416011609 Ultra-IBC Spill Pallet Plus Ultra-Bucket Shelf (Part #1160)
- UPC 808416011593 Ultra-IBC Spill Pallet Plus Pull Over Cover (Part #1159)
WARNING: Part #1159 can expose you to chemicals including Di(2-ethylhexyl) phthalate (DEHP) which is known to the state of California to cause cancer, birth defects, or reproductive harm. For more information, please visit www.P65Warnings.ca.gov
