Portable containment unit captures railcar leaks and spills
Leaky locomotives and tanker cars can wreak environmental havoc on a railroad site. For loading areas, maintenance locations and other sections where leaks and spills are frequent, a more permanent spill containment system like the Ultra-Track Pans is an excellent solution.
But for a portable spill containment / spill response solution, the Ultra-Track Berm may be just the right answer. The track berm is portable enough to be quickly and effectively moved by one person to a leak or spill and can capture up to 144 gallons.
If a larger spill occurs or greater capacity is needed, drain hoses (not included) can be connected to the camlock fittings so the spilled material is directed to a waste collection area or larger container.
Product Highlights
- Lightweight and portable spill containment unit is easily placed under leaking/spilling railcars.
- Dual-sump design provides protection for area on either side of the rail.
- Two (2) stainless steel camlock fittings allow quick and leak-free drainage of spilled chemicals.
- Closed-cell polyethylene (LLDPE) foam provides secure sidewall structure.
- Durable 40oz. (42 mil) PVC construction withstands harsh railroad conditions and provides excellent chemical compatibility.
NOTE: Unless otherwise noted, all listed product measurements are L x W x H, outside dimensions, and for a single unit where quantity is more than one.
| Part # | Model | Dimensions in. (mm) | Containment Capacity gal. (L) | Weight lbs. (kg) |
|---|---|---|---|---|
| 8490 | 40 oz. (42 Mil) PVC | 72 x 48 x 12 (1828.8 x 1219.2 x 304.8) | 144 (545) | 24.0 (10.9) |
Swipe to scroll table
| Part # | Model | Product Image | Dimensions in. (mm) | Weight lbs. (kg) |
|---|---|---|---|---|
| 8298 | PE Repair Tape 4" |  |
600 x 4 x 6 (15240 x 101.6 x 152.4) | 3 (1.4) |
| 8299 | PE Repair Tape 6" | |
600 x 6 x 6 (15240 x 152.4 x 152.4) | 6 (2.72) |
Swipe to scroll table
Convert This Containment Berm Into a Plastic Pellets Containment Berm
If you need to contain plastic pellets (“nurdles”), this containment berm can be shipped with one or more 6″ drains to provide quick draining of water while still containing plastic pellets.
FAQs
Resources & Docs
Compliance & Regs
Additional Info.
FAQs
Frequently Asked Questions
Resources & Docs
Compliance & Regs
This product may not address any specific regulations but if you have any questions, we’re here to help.
Additional Info.
Additional Product Information
Uniform Product Codes (UPCs)
- UPC 808416084900 Ultra-Track Berm 40 oz. (42 Mil) PVC (Part #8490)
- UPC 808416102468 Ultra-Containment Berm® PE Repair Tape 4" (Part #8298)
- UPC 808416102475 Ultra-Containment Berm® PE Repair Tape 6" (Part #8299)
WARNING: Part #8490 can expose you to chemicals including Di(2-ethylhexyl) phthalate (DEHP) which is known to the state of California to cause cancer, birth defects, or reproductive harm. For more information, please visit www.P65Warnings.ca.gov
